Overview
140 tons with the reach to match.
The TCC-1400 carries Link-Belt’s telescopic crawler design up to a six-section boom that extends to 195.4 ft, riding on a crawler undercarriage built to keep working on ground a wheeled crane would avoid. With the three-piece bi-fold fly configured, it reaches a 257 ft 7 in tip height, among the tallest in the telescopic crawler line.
A Cummins QSL9 (320 hp) drives the crane through a two-speed travel system rated to 40 percent gradeability. Link-Belt Pulse handles the rated capacity limiter with live and simulated ground bearing pressure readouts, along with cellular telematics for fleet monitoring.
Six-section boom
Six-piece counterweight
Link-Belt Pulse
Crawler undercarriage
Tilting cab
Why the TCC-1400
Six sections, nearly 258 ft of reach.
Link-Belt Pulse
Integrated rated capacity limiter with live and simulated ground bearing pressure readouts and cellular telematics.
Three fly configurations
From a single 10 ft fly to a 10-31-55 ft three-piece bi-fold, reaching up to 257 ft 7 in tip height.
Six-piece counterweight
An ABCD upper set plus two carbody pieces totals up to 82,000 lb, matched to the boom’s reach.
Tilting cab
A 0 to 20 degree tilting operator’s cab keeps the view on the load through steep boom angles.
Teflon-lined boom wear pads
Self-lubricating wear pads on the six-section boom reduce daily grease points.
Telematics standard
Cellular location, usage, maintenance, and fault-code monitoring, so your fleet team sees the machine before it calls in.
Specifications
The full technical picture.
Representative specifications for the Link-Belt TCC-1400. Always refer to the in-cab Crane Rating Manual for allowable lifting capacities.
Lifting & Boom
| Maximum rated capacity | 280,000 lb (140 USt) @ 8 ft |
| Main boom | 42.4 – 195.4 ft (12.9 – 59.5 m) |
| Boom sections | Six, formed construction |
| Boom extend modes | Five (EM1–EM5) |
| Boom elevation | −2.5° to 81° |
| Max tip height (main boom) | 203 ft (61.9 m) |
| Max tip height (3-piece fly) | 257 ft 7 in (78.5 m) |
| Fly | Up to 10–31–55 ft three-piece bi-fold lattice, offset 0–45° |
| Counterweight | Up to 82,000 lb, “ABCD+A” configuration |
Engine & Hydraulics
| Engine | Cummins QSL9, 6-cyl diesel |
| Rated power | 320 hp (239 kW) @ 1,800 rpm |
| Peak torque | 1,050 ft·lb (1,424 N·m) @ 1,500 rpm |
| Emissions | Tier 4f / Stage IV |
| Fuel tank | 110 gal (416 L) |
| Hydraulic reservoir | 250 gal (946 L) |
Undercarriage & Travel
| Track shoe width | 36 in (0.91 m) |
| Side frame gauge, extended | 15 ft 2.2 in (4.63 m) |
| Side frame gauge, retracted | 8 ft 11.6 in (2.73 m) |
| Overall undercarriage length | 23 ft 4.2 in (7.11 m) |
| Max travel speed | 2 mph (3.2 km/h) |
| Gradeability | 40% |
| Ground bearing pressure | 13.94 psi (0.98 kg/cm²), soft ground |
Winch & Tech
| Drum diameter | 15 in (38.1 cm) |
| Main rope length | 900 ft (274.3 m) |
| Wire rope | 7/8 in, Type ZB |
| Max line pull | 22,380 lb, layer 1 |
| Swing speed | 1.2 rpm, 360° continuous |
| Operating system | Link-Belt Pulse |
| Transport weight | 93,600 lb (42,456 kg) |
⬇
TCC-1400 Technical Data
Full specifications & capacity charts (PDF)
↗
TCC-1400 Official Page
Full details at linkbelt.com
Questions, answered
Link-Belt TCC-1400 FAQ
How much can the Link-Belt TCC-1400 lift?
The Link-Belt TCC-1400 has a maximum rated capacity of 280,000 lb, 140 US tons, at an 8-foot radius.
What is the maximum tip height of the TCC-1400?
Maximum tip height is 203 ft on the main boom alone in its longest extend mode, and up to 257 ft 7 in with the three-piece bi-fold lattice fly.
What engine powers the Link-Belt TCC-1400?
A Cummins QSL9 six-cylinder diesel producing 320 hp (239 kW) at 1,800 rpm.
How long is the main boom on the TCC-1400?
The TCC-1400 uses a six-section formed boom that extends from 42.4 ft to 195.4 ft, with five operator-selectable extend modes.
What counterweight does the TCC-1400 carry?
The TCC-1400 uses a six-piece counterweight system, four upper pieces plus two carbody pieces, totaling up to 82,000 lb in its full ABCD+A configuration.
Can I rent or buy a Link-Belt TCC-1400 from HOLT?
Yes. HOLT Crane & Equipment sells and rents the Link-Belt TCC-1400 across north, northeast, central, and west Texas, and southern New Mexico, backed by factory-trained service and genuine parts. Call 877-275-1520 for availability.
Put a TCC-1400 on your next lift.
Tell us the job and we’ll match the machine, for sale or rental, with the parts and service to keep it lifting.
