Overview
Nimble on the road, capable on site.
The 65|RT is the entry point to Link-Belt’s rough terrain line, and the quickest one on the road: a top travel speed of 25 mph gets it between sites faster than any other RT model. Its four-section boom telescopes to 115 ft, and with the bi-fold fly plus two 16 ft lattice extensions it reaches a 211.6 ft tip height.
The 65|RT runs on Link-Belt Pulse, the operating system with an integrated rated capacity limiter and telematics, paired with CALC confined-area outrigger positioning. Four steering modes and 4×2/4×4 drive get it into position; a Cummins QSB6.7 gets it there.
Four-section boom
CALC outriggers
Pulse
Tier 4F
25 mph travel
Why the 65|RT
Small footprint, quick on its feet.
Pulse operating system
Integrated RCL, anti-two-block, real-time load and radius, operator-set alarms, and telematics monitoring.
CALC outriggers
Confined-area lifting capacities with full, intermediate, and retracted extension positions.
Four steering modes
Two-wheel front, two-wheel rear, four-wheel, and crab, plus 4×2 and 4×4 drive for off-highway travel.
Four-section boom
38 to 115 ft of full-power boom with standard and A-Max extend modes for the tightest working envelope in the line.
25 mph travel speed
The quickest RT model on the road, cutting the time and cost of moving between jobsites.
All-day cab
Fully enclosed cab with air conditioning, tinted glass, and LED lighting including the Vision Package as standard.
Specifications
The full technical picture.
Representative specifications for the Link-Belt 65|RT. Always refer to the in-cab Crane Rating Manual for allowable lifting capacities.
Lifting & Boom
| Maximum rated capacity | 65 US tons (60 mt) @ 9 ft |
| Main boom | 38 – 115 ft (11.6 – 35.0 m) |
| Boom sections | Four, full-power construction |
| Boom extend modes | Two (Standard, A-Max) |
| Boom elevation | −3° to 78° |
| Max tip height (standard mode) | 123 ft 9 in (37.7 m) |
| Max tip height (fly + 2 lattice ext.) | 211 ft 7 in (64.5 m) |
| Fly | 35 – 58 ft bi-fold, offsettable 0–45° |
| Counterweight | 12,000 lb (5.4 t) |
Engine & Drivetrain
| Engine | Cummins QSB6.7, 6-cyl diesel |
| Rated power | 270 hp (201 kW) @ 2,000 rpm |
| Peak torque | 730 ft·lb (990 N·m) @ 1,500 rpm |
| Emissions | Tier 4F / Stage IV (Tier 3 avail.) |
| Transmission | Powershift 3-speed, 6F / 6R |
| Drive | 4×2 and 4×4 |
| Max travel speed | 25 mph (40.2 km/h) |
| Gradeability | 31% (12,000 lb counterweight) |
| Fuel tank | 75 gal (283.9 L) |
Carrier & Outriggers
| Carrier width | 10 ft 7 in (3.22 m) |
| Wheelbase | 14 ft 7 in (4.45 m) |
| Steering modes | Front, rear, four-wheel, crab |
| Tires | 26.5 × 25, 26-ply earthmover |
| Outriggers | Four single-stage, CALC |
| Main jack reaction | 90,500 lb (41,050 kg) |
Winches, Swing & Tech
| Main winch rope (rear) | 600 ft (182.9 m), 3/4 in |
| Aux winch rope (front, optional) | 500 ft (152.4 m), 3/4 in |
| Max line pull | 16,883 lb (75.1 kN) |
| Swing | 360° continuous @ 2.0 rpm |
| Operating system | Link-Belt Pulse |
| Monitoring | Telematics standard |
⬇
65|RT Technical Data
Full specifications & capacity charts (PDF)
⬇
65|RT Brochure
Overview & feature highlights (PDF)
On the job
The 65|RT at work.
Questions, answered
Link-Belt 65|RT FAQ
How much can the Link-Belt 65|RT lift?
The Link-Belt 65|RT has a maximum rated capacity of 65 US tons (60 metric tons) at a 9-foot radius.
What is the maximum tip height of the 65|RT?
Maximum tip height is 123 ft 9 in (37.7 m) on the main boom in standard extend mode, and up to 211 ft 7 in (64.5 m) with the bi-fold fly plus two 16 ft lattice extensions.
What engine powers the Link-Belt 65|RT?
A Cummins QSB6.7 six-cylinder diesel producing 270 hp (201 kW) in Tier 4 Final configuration, or 260 hp in Tier 3 / Stage IIIA.
How long is the main boom on the 65|RT?
The 65|RT uses a four-section full-power boom that extends from 38 ft to 115 ft (11.6 to 35.0 m), with standard and A-Max extend modes.
What makes the 65|RT different from the rest of the line?
It’s the smallest and fastest crane Link-Belt builds in rough terrain, with a 25 mph top travel speed and a more compact four-section boom. It runs Link-Belt’s Pulse system and CALC outriggers, the earlier-generation technology that several larger |RT models have since upgraded to Pulse 2.0 and V-CALC.
Can I rent or buy a Link-Belt 65|RT from HOLT?
Yes. HOLT Crane & Equipment sells and rents the Link-Belt 65|RT across north, northeast, central, and west Texas, and southern New Mexico, backed by factory-trained service and genuine parts. Call 877-275-1520 for availability.
